DESCRIPTION

Basic Info.

Model NO.	titanium, nickel, stainless steel, copper
Surface Treatment	Polished
Width	up to 2000mm
Length	UPT to 8000mm
Standards	ASTM B898,ASTM B263
Transport Package	Wooden Case
Specification	acc to the ASME specifications or others
Trademark	Tongji Engineering
Origin	China
HS Code	8404909000
Production Capacity	50000PCS

Product Description

Maitan provides precision tubesheets with various materials include wide range of clad steel consisting of corrosion resistant materials. We are strict to use of high quality and guaranteed raw material , proved by raw material certificate with each delivery.
CNC drilled, chamfer, grooved etc as the drawings' requirements.
Tube holes can be drilled and reamed and can be machined with one or more grooves. This greatly increases the strength of the tube joint.

Type of materials	Technical requirements * according to
Duplex Stainless Steel	ASTM/ASME SA182 F44, F45, F51, F53, F55, F60, F61
Stainless Steel	ASTM/ASME SA182 F304,304L,F316,316L, F310, F317L, F321, F347
Carbon Steel	ASTM/ASME A105, A350 LF1, LF2, A266, A694, A765 Gr.2
Alloy Steel	ASTM/ASME SA182 F1, F5, F9, F11, F12, F22, F51, A350-LF3
Non Ferrous	Titanium, Brass, Al-Brass, Copper Nickel, Nickel Alloys, Hastelloy
Titanium	ASTM/ASME SB381, Gr.1, Gr.2, Gr.5, Gr.7, Gr.12, Gr.16
Copper Nickel	ASTM/ASME SB151, UNS 70600(Cu-Ni 90/10), 71500(Cu-Ni 70/30)
Brass, Al-brass	ASTM/ASME SB152 UNS C10100, C10200,C10300,C10800,C12200
Nickel Alloys	ASTM/ASME SB169,SB171, SB564, UNS 2200, UNS 4400, UNS 8825 UNS 6600, UNS 6601, UNS 6625
Alloy 20	ASTM/ASME SB472 UNS 8020
Hastelloy	ASTM/ASME SB564, UNS10276 ( C 276 )
Claded materials	ASTM/ASME SB898, SB263, SB264 or closer explosion cladding, making materials of 2 in 1 or 3 in 1.
	Titanium- Steel, Nickel-Steel,Titanium- Copper, Stainless Steel- Carbon Steel, Alloys- Steel etc.
